FrSky Tandem X18

Description

If you’re in the market for a new radio with a focus on lightweight comfort and advanced features, the FrSky Tandem X18 series is a perfect choice, especially with its powerful ETHOS system. The dual-band Tandem X18 radios feature an ergonomic design with rounded hand grips and a stable case, making them comfortable to hold and easy to use. Accessible sliders and switches, along with four standard stick trims plus two extra trims, provide unmatched flexibility for in-flight adjustments. Additionally, the X18 series incorporates integrated flash storage for simplified data handling and a streamlined internal design that prioritizes both space and weight, all while delivering the full ETHOS experience.

Internal 900MHz/2.4GHz Dual-Band & External Module Bay

The TD dual-band RF system combines both the features and advantages of FrSky 900MHz and 2.4GHz RF together in one system. The TD features real simultaneous dual-band longrange control with telemetry that achieves reliable end-to-end 4ms latency while maintaining a robust and high-quality signal link. The entire range of TD, ACCESS & ACCST D16 receivers are supported. The built-in TANDEM RF System supports ACCESS and ACCST D16 protocols.

In addition, the Tandem X18 series radios include a rear Lite version module bay to offer more options to connect external devices. FrSky welcomes working compatibility with the 3rd party products with their own developed technology following FrSky verified 3rd party compatibility-testing program.

ETHOS Operating System

ETHOS is a thoroughly new operating system, designed from the ground up by RC experts, providing users a powerful, intuitive, and flexible experience that can maximize the fun of RC Hobby!

FrSky Tandem X18 Features

Hardware

• Enhanced ergonomic designed case with comfortable rounded hand grips
• 4 Standard Trims with additional 2 extra trims
• Integrate flash storage but also keep the internal TF card slot
• Easy-to-reach top switches and sliders
• With a flat base to improve stability when standing the radio
• Color Touch-Screen Displays
• High-Precision Hall-Sensor Gimbals with a Metal Panel
• 6 Quick-Mode Custom Buttons (Front) and 2 Momentary Buttons (Rear)
• Lite Type External Module Bay
• Haptic Vibration Alerts and Voice Speech Outputs
• Supports Recharge System for 2S Li-ion Battery (USB Type-C Interface)
• High-speed PARA Wireless Training System

TD-ISRM RF Module

• Built-in TD 900M/2.4G Dual-Band Internal RF Module
• Supports Multiple Working Modes
  • 2.4G ACCST D16 Mode (Compatible with ACCST Receivers with D16 V2 or later FW)
  • 2.4GACCESS Mode (Compatible with ACCESS Receivers)*
  • 900M ACCESS Mode (Compatible with ACCESS R9 868/915MHz Receivers)*
  • (*Capable of simultaneous working under ACCESS mode)
  • 2.4G & 900M TD Mode (Compatible with TD Receivers)
• Long-range control and super-low latency with telemetry
• (*Up to 50 to 100KM range and down to 4ms end-to-end latency)

ETHOS System

• Clear and Intuitive UI Design
• Supports Dual Operation Modes of Radio Display (Touch and Non-Touch)
• Supports Multi-Language Switching
• Hardware/Software Version and Factory Version Detection
• Supports running LUA Scripts

FrSky Tandem X18 Specifications

• Dimension: 200*192*95mm (L*W*H)
• Weight: 687g (Battery Excl.) / 820g (Battery Incl.)
• Operating System: ETHOS
• Internal RF Module: TD-ISRM
• Number of Channels: Up to 24 channels
• Operating Voltage Range: 6.5 ~ 8.4V (2S Li-battery)
• Operating Temperature: -10°C~60°C (14°F~140°F)
• Operating Current: [email protected] (typ.)
• Charging Current: ≤1A ±200mA
• USB Adaptor Voltage: 5V+0.2V
• USB Adaptor Current: >2.0A
• Backlit touchable LCD resolution: 480*320
• Compatibility: ACCST D16 & ACCESS & TD receivers
